• Durability: higher wear resistance due to increased hardness
• Simple: smart and easy assembling of chain slings
• Traceability: appropriate marking on chains & components
• Reliability: Decades of experience
• Strong: 50 % higher load capacity compared to Grade 8, 20 % higher load capacity compared to Grade 10
Part Code | Size (mm) | Pitch (mm) | Li Min (mm) | Le Max (mm) | Weight (kg/m) | WLL (kg) | Breaking Load (kN) |
---|---|---|---|---|---|---|---|
KWB-CHAIN07 | 7 | 21 | 9.8 | 26.0 | 1.33 | 2,360 | 92.6 |
KWB-CHAIN08 | 8 | 24 | 11.0 | 30.5 | 1.69 | 3,000 | 118 |
KWB-CHAIN10 | 10 | 30 | 14.3 | 38.0 | 2.66 | 5,000 | 196 |
KWB-CHAIN13 | 13 | 39 | 18.0 | 48.5 | 4.43 | 8,000 | 319 |
KWB-CHAIN16 | 16 | 48 | 21.5 | 59.0 | 6.73 | 12,200 | 479 |
